Core Advantages of Four Column Upper-cylinder CNC Hydraulic Press DSBS
1. Servo-Precision Drive
0.01s fast response, ±1%FS pressure control accuracy, and ≤0.02mm displacement repeat positioning. Ensures precise process replication for complex forming and precision pressing, reducing defect rates.
2. Upper Cylinder Design
Unobstructed workbench with ample loading/unloading space. Customizable size adapts to various workpieces; easy integration with automatic systems for high production flexibility.
3. Energy-Saving & Cost-Effective
Intelligent power adjustment cuts energy consumption by 30%-50% vs. traditional presses. Lower oil temperature rise reduces cooling energy use and hydraulic oil replacement frequency.
4. Stable Heavy-Duty Performance
High-quality imported hydraulic components and stress-relieved body structure. Servo drive minimizes mechanical impact, extending MTBF by over 40% and overall service life.
5. Intelligent Operation
HD touchscreen for parameter storage/calling. Built-in fault self-diagnosis and MES compatibility enable easy maintenance and intelligent production traceability.
6. Comprehensive Safety
Complies with international standards, equipped with infrared safety light curtains, emergency stop, and overload protection. ≤75dB operation for a safe, quiet workspace.

Product Application

1. Stamping , forming , shallow , drawing and pressing assembly etc.
2. Forming of spectacle parts , lock parts , metal hardware , pressing assembly of electronic connectors , electric components and rotor & stator of motor etc.
3. Suitable for cold forging , warm forging, hot forging, and applicable to liquid metal forming and ceramic powder metallurgy pressing forming.

Technical Parameters

DSBS-A Cylinder Half Type Single Movement Hydraulic Press
The parameters are for reference, ordering the contract shall prevail.

DSBS-A series can according to customer's requirement.

Product Advantage

 1. Use servo control system to save energy 50-70%.
2. Pressure stability, pressure error ±1bar, repeatable positioning accuracy up to±0.02mm.
3. Low failure rate, automatic alarm and fault indication, one-button reset function.
4. Remote maintenance service can be realized.
5. Can set up multi-stage pressure, multi-speed and continuous fixed-pressure function.
6. Adopting an integral frame structure, high strength, low distortion and durability.
7. Eight-sided rigid guide rails have good guide precision, strong side pressure resistance and easy maintenance.
8. Suitable for cold forging , warm forging, hot gorging, and applicable to liquid metal forming and ceramic powder metallurgy pressing forming.
